H999 Clear is a high-performance, double-coated acrylic foam tape designed for permanent bonding in interior and exterior applications.
Its viscoelastic acrylic foam core combines flexibility with long-term strength, allowing the tape to conform to microscopic surface irregularities, distribute stress and accommodate movement caused by vibration or thermal expansion.
The clear construction provides a discreet finish, while its strong acrylic adhesive creates a secure bond across a wide range of substrates. H999 Clear is particularly suitable for bonding ACM and Dibond panels to channelling, as well as mounting signs, nameplates, emblems and metal components.
With excellent resistance to UV, moisture, solvents and ageing, it provides reliable performance in demanding signage, display and fabrication applications.
Key Features
- High-strength permanent bonding tape
- Double-coated acrylic foam construction
- Viscoelastic core conforms to minor surface irregularities
- Helps absorb vibration and dynamic loads
- Distributes stress across the bonded area
- Accommodates thermal expansion and movement
- Excellent resistance to UV, moisture and solvents
- Suitable for interior and exterior applications
- Clear colour for a discreet finish
- Strong long-term ageing resistance
- Suitable for a wide range of substrates
Applications
- Bonding ACM or Dibond to channelling
- External sign construction
- Sign trays and panels
- Nameplates
- Emblems and badges
- Metal components
- Decorative trims
- Display fabrication
- Interior and exterior mounting
- General permanent assembly
Product Specifications
- Product code: H999
- Tape type: Double-coated acrylic foam tape
- Width: 25mm
- Roll length: 33m
- Total thickness: 1.0mm
- Colour: Clear
- Carrier: Acrylic foam
- Adhesive: Acrylic
- Liner: Red low-density polyethylene film
- Adhesive strength: 29 N/25mm
- Dynamic shear: 5kg/cm²
- Service temperature: -40°C to +93°C
- Short-term temperature resistance: Up to +150°C
- Recommended application temperature: +15°C to +30°C
- Shelf life: Minimum of two years when stored correctly
Application Recommendations
For the strongest bond, ensure that both surfaces are clean, dry and free from dust, grease and other contaminants.
Apply the tape at a temperature between +15°C and +30°C and use firm, even pressure across the bonded area. The indicated performance level is achieved after a bonding period of approximately 24 hours at +23°C.
